SMW7J | 7" System | "J" Series
The SMW7J is our "J" series camera system that uses our wide angle C300P camera for an expanded field of view. Learn more about the specs and see photos below.
Here is what's included in this complete system:
-
7" Monitor (MK07J)
-
193 degree camera (C300P)
-
J Series Mount (ADD22H)
-
65' Camera Cable (20m)
-
Monitor Power Cable (CB400J)
-
Allen Wrench & Vibration Pad
-
Instruction Manual
When you purchase a Verity rear vision system, you're getting a quality product and great customer service! Our team is available to answer any questions your engineers or installers may have.
Fleets & OEMS Call for Pricing 574-807-6005
Verity's MK07J 7" Monitor
MONITOR SPECIFICATIONS
(Monitor part #MK07J)
-
7” LED-backlit LCD panel for longer life and high resolution.
-
3 Camera inputs (audio and video) with color-coded trigger wires making it easy to add your choice of Verity side cameras, interior cameras, or forward-facing cameras.
-
SM07J system comes with (1) night vision camera.
-
This system can also be ordered in a quad view.
-
61" monitor harness with waterproof fuse and color-coded trigger wires.
-
The auto-dimming monitor screen and buttons are designed for commercial use. Ideal for unstable cab light; works steadily in situations like tree-covered roads or city blocks.
-
The very high contrast level of 700:1, made more advanced with a Brightness level of 520 cd/m2
-
High resolution of 1024*600
-
The heavy-duty, removable sun shield is strong enough to hold our aftermarket sensor display.
-
Power supply rating: 12V~24 V DC with reverse polarity protection. Verity does not overinflate our ratings. When we QC each production run, we test this system from 8 v. to 34 v.
-
The system format is NTSC/PAL/AUTO allowing for domestic and export use.
-
Easy to use the On-Screen menu helps to prevent improper adjustment of functions.
-
Back-up guidelines can be on/off and can also be adjusted to match the truck.
-
Multi-languages inducing, Spanish and French.
-
The image can flip horizontally (mirrored/unmirrored) or vertically.
-
Operation temperatures: -20°~70°C
-
Storage temperature: -30°~80°C
-
Includes 65’ camera extension cable with water-proof aviation plugs. Cable has copper connections not zinc.
If an optional remote is supplied, batteries are not included.
The “J” Series has had a 0.022% issue rate over the past 9+ years combined.
Backed by our 24/7 tech support for fleets and OEMs
-
Adjustable backup lines both vertically and horizontally to match your vehicle.
-
Monitors will self-diagnose certain problems.
-
Scan feature to scan camera inputs
Learn About Our C300P Wide Angle Camera
Our 193 Degree Legal Vision Camera
Our secret is in our image processing system which crops out the “fish eye” look and provides a crisp clear image.
The resulting image surpasses the requirements of the new Backup Camera Law - even from heights as low as 32 inches off the ground!
Our technology will work on normal box truck heights with the least distortion to the image.
CAMERA SPECIFICATIONS
-
NO Audio
-
Horizontal Resolution: 700 TV Lines
-
Effective Pixel: 510 x 492
-
Illumination: 1.5 Lux
-
Viewing Angle: 193°
-
Waterproof: IP69
-
Shockproof: 10G
-
Operating Temperature: -40°~70°C
-
Power Supply: DC 12V (powered by monitor)
-
Optional Add-On: ADD300Z cast aluminum camera cover
The camera housing ball of our C300P camera provides "Witness Marks" to aid your testing and certifications.
Set each camera to the same mark, install in the exact same spot on each truck saving testing time.
SMW7J System Also Includes:
CB021 20 Meter (65 Feet)
F/F Camera Extension Cable
Manual
Optional Camera Cover protects camera from damage and theft
Optional Add-On: ADD300Z cast aluminum camera cover
Competitors do not have the C300P solution
because it is exclusive to Verity
The below charts will enlarge by clicking on them.
These charts show the field of view comparison of the C300P to
a normal field of view camera.
Optional "J" Series Cameras
CAMERA EXTENSION CABLES
J-Series Camera Extension Cables
4-Pin female/female
CB011: 1 meter ( 3’) 4-pin camera cable
CB006: 5 meter (15’) 4-pin camera cable
CB012: 10 meter (33’) 4-pin camera cable
CB018: 15 meter (49’) 4-pin camera cable
CB021: 20 meter (65’) 4-pin camera cable
(*special order/custom sizes available)
